Lockwood 1814-70 External Plate with Privacy Indicating Emergency Turn and 70 Lever - Satin Chrome
MPN
1814/70SC
SKU
LW1814-70SC
Stock Availability - Delivery & In Store
| Delivery | In Stock | Ready for Dispatch |
| Adelaide | In Stock | 16 |
| Brisbane | In Stock | 5 |
| Darwin | Low Stock | 4 |
| Gold Coast | In Stock | 11 |
| Hobart | In Stock | 36 |
| Launceston | In Stock | 19 |
| Melbourne | In Stock | 43 |
| Sydney | In Stock | 16 |
| Distribution Centre | Out of Stock | Order Now: ETA 5-10 days |
- Dimensions - 166mm x 48mm x 12mm
- Suits 32mm - 50mm timber doors (separate extended screws available)
- 70 style lever handle also for AS1428.1 compliance
- Satin chrome finish
- 25 year manufacturer's mechanical warranty
- 10 year manufacturers finish warranty
- Suits Lockwood 3570 series mortice locks
- Australian made
- Fire rated (4hrs)
- S3 security & D3 durability rating (AS4145.2-1993)
| MPN | 1814/70SC |
|---|---|
| Brand | Lockwood |
| Product Width | 48mm |
| Product Height | 166mm |
| Product Warranty | 10 Years Finish, 25 Years Mechanical |
| Product Length | 121mm |
| Projection or Length | 53mm |
| Plate Shape | Rectangle Plate |
| Plate Thickness | 12mm |
| Product Finish or Colour | Satin Chrome (SC) |
| Product Material | Brass |
| Includes Fixing Screws | Yes |
AS1428.1 Compliant AS1428.1 CompliantComplies when installed to Local Building Codes and when used with compliant accessories. Check with local legal requirements to ensure you meet the specification. | Yes |
Fire Tested Fire TestedDifferent products are fire tested for use with specific fire rated doors only. Ensure you check with the manufacturer that this product is suitable for the door it is intended to be installed on. | Yes |
| Suitable for Door Type | Timber Doors, Aluminium Doors |
| Handing | Non-Handed |
| Cylinder Cut Out Profile | No |
| Spindle Size | 7.6mm |
| Fixing | Concealed Fixed |
| Max Door Thickness | 45mm |
| Suitable for | Commercial, Residential |
| Shop by Collection | Lockwood 1800 Series |
